Booth #: J1118, J1120, J1217, J1219 TWTC Nangang Exhibition Hall ** LyCOM NVMe Products for M.2 & U.2 SSD ** M.2 Key ID and LyCOM Various M.2 Product The M.2 NGFF form factor is 75 Pins rectangular PCBA with an edge connector used for Mobile Add-In cards. Different M.2 module uses the different M.2 Key ID connector and has the different notched pin and signal interface, like below 1. M Key M.2 (Notched Pin 59-66) use on NVMe SSD 2. B Key M.2 (Notched Pin 12-19) use on SATA SSD or 3G/4G WWAN card 3. E Key M.2 (Notched Pin 22-31) use on WiFi card For example, most mainboard only implement M.2 M Key socket, but due to the Key insertion prevention, user can’t install advanced popular E Key WiFi module into mainboard incompatible M Key host socket directly.
DT-120 PCIe 3.0 x4 Host Adapter for M.2 NGFF PCIe SSD installed in Main Board Make High Performance PCIe Gen3 based M.2 NGFF SSD to work in desktop main board with Regular Size & Low Profile PCIe brackets support! Lycom PE-114M Low Profile PCIe 2.0 Host Adapter for Mac and Windows Lycom PE-114M eSATA III-6Gbps External 2Ports Low Profile PCIe 2.0 Host Scan code: LN33816 Manufacturer code: PE-114M. Make High Performance PCIe Gen3 based M.2 NGFF SSD to work in desktop main board with Regular Size & Low Profile PCIe brackets support! Note, this adapter is designed only for 'M' key M.2 PCIe x4 SSD's (pictured below left), such as the Samsung XP941 or SM951. Lycom DT-122 M.2 SATA SSD to PCIe HHHL Adaptor Lycom DT-122 2x 110mm M.2 SATA SSD Low Profile PCIe 2.0 Host Adapter, HHHL, PCI 2.0 x4 (x2 Lane) 10Gbps, SATA III 6Gbps.
Recently more and more advanced and fast M.2 modules or SSD available in the market, so user actually need the vast type of M.2 converter board to enjoy M.2 new technologies on their PCIe mainboard, or mini-PCIe mainboard, or even different Key M.2 mainboard. LyCOM M.2 Converter for PCIe or mini-PCIe or M.2 mainboard: 1. For NVMe SSD ( M Key M.2) (1-1) PCIe mainboard use M.2 NGFF NVMe SSD to PCIe 3.0 x4 Host Adapter 1x NVMe + 2x SATA Three 22110 M.2 SSD Low Profile PCIe 3.0 x4 Carrier Adapter PCIe 3.0 x4 3.3V5A Host Adapter for M.2 NVMe 110mm SSD PCIe 3.0 x4 Carrier Adapter for M.2 NVMe 110mm High Power SSD Dual PCIe NVMe M.2 SSDs Carrier Adapter (1-2) M.2 mainboard use NGFF M.2 M-Key to M-Key Riser Card 2.
For SATA SSD or 3G/4G WWAN card ( B Key M.2) (2-1) PCIe mainboard use M.2 B Key to PCIe Adapter for 3G 4G WWAN M.2 Module (2-2) mini-PCIe mainboard use M.2 B Key to miniPCIe Adapter for 3G 4G WWAN M.2 Module (2-3) M.2 mainboard use NGFF M.2 B-Key to B-Key Riser Card 3. For WiFi card or LAN card ( E Key M.2) (3-1) PCIe mainboard use M.2 E Key to PCIe Adapter for M.2 WiFi Module (3-2) mini-PCIe mainboard use M.2 E Key to miniPCIe Adapter for M.2 WiFi Module (3-3) M.2 mainboard use M.2 E Key to M Key Adapter for M.2 WiFi Module LyCOM M.2 Module or Host Adapter 1. M Key M.2 M.2 M Key Module with miniSAS HD 36P to U.2 NVMe SSD M.2 M Key Module with miniSAS HD 36P (Upward) to U.2 NVMe SSD M.2 E Key to M Key Adapter for M.2 WiFi Module NGFF M.2 M-Key Riser Card 2. B Key M.2 NGFF M.2 B-Key Riser Card 3. B- M Key M.2 Fast PCIe Base M.2 B-M Key Module to Micro SD 3.0 2x SATA 6Gbps M.2 NGFF Host Module 4.
A -E Key M.2 GigaLAN 1000BASE-T Ethernet PCIe x1 M.2 A-E Key Module GigaLAN 1000BASE-T Ethernet PCIe x1 M.2 A-E Key Module (Right Angle RJ-45) Fast PCIe Base M.2 A-E Key Module to Micro SD 3.0 RS232 M.2 A-E Key Module Welcom to visit our web-site The latest update on: 2018/08/16.
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.
Use: PCIe 3.0 x4 Host Adapter for M.2 NGFF PCIe SSD Manufacturer warranty: 1 year EAN: 107 To Fit: M.2 NVME PCIe SSD up to 2280 MPN: Dt-120 Model: DT-120 Brand: Lycom Type: PCI Express 3.0 x4 Lane Host adapter Country/Region of Manufacture: Taiwan UPC: Does not apply Interface: PCI Express 3.0 x4.
Pcie 2.0 Motherboards
Product Description Lycom DT- 120 PCIe 3.0 x4 Host Adapter for M.2 NGFF PCIe SSD installed in Main Board Make High Performance PCIe Gen3 based M.2 NGFF SSD to work in desktop main board with Regular Size & Low Profile PCIe brackets support! Note, this adapter is designed only for 'M' key M.2 PCIe x4 SSD's (pictured below left), such as the Samsung. It will not work with a 'B' key M.2 PCIe x2 SSD or the 'B' key.
Lycom Pe114m Low Profile Pcie 2.0 Host Adapter For Mac
For the 'B' key M.2 SATA SSD's you will need the. • 5 lYCOM CONVERTER Posted by Talat hashim on 7th Dec 2015 Nice product to convert your M.2 card to use PCIe slots and very small and easy to install • 5 Brilliant product. Highly recommended for PC enthusiasts!! Posted by X on 4th Dec 2015 I've just given myself an early christmas present, a new PC! I7-6700k with ASUS Maximum VIII Hero motherboard. Installing the SM951 SSD in this adapter has given me the best possible benchmark results in CDM, in excess of 2200MBs read and 1200MBs write.
